AirPro Comfort 2-20 monobloc heat pump | Hargassner

Heat Pump

AirPro
2-20 kW
COMFORT

Propane heat pump
Compact hot water storage tank & one heat circuit
Energy efficiency class A++ / A+++

Download brochure
  • Compact system solution in one unit
  • Quick installation with reduced space requirements
  • Direct heat circuit already integrated
  • Centralised control of the entire heating system
  • 7-inch colour display with touch function

COMFORT heat pump

Compact indoor unit including integrated hot water tank and heat circuit

The “COMFORT” indoor module combines the central hydraulic components of the heat pump system with an integrated hot water storage tank in one compact unit. This reliably covers both the heating supply and hot water preparation. The complete cooling circuit is housed in the outdoor unit, which means that the indoor installation is focussed on the hydraulic integration.

Benefits:
AirPro COMFORT

Download brochure
  • 310-litre hot water storage tank with integrated protective anode
  • 3-way changeover valve for automated hot water preparation
  • Infinitely variable high-efficiency circulation pump
  • Integrated direct heat circuit for system connection
  • Magnetic dirt separator to protect the hydraulic components
  • Safety group integrated at the factory
  • Electric heating element with automatic power adjustment (3 / 6 / 9 kW)
  • Compensation tank with 12 litre volume
  • Simple and quick installation
  • Attractive, modern design
  • Extremely weather-resistant thanks to galvanised, powder-coated metal housing
  • Low-noise operation with only 39 dB according to EN 12102
  • Very good energy efficiency with a SCOP of over 5
  • Energy efficiency class up to A+++
Included hydraulic components in addition to the STYLE equipment: 3-way changeover valve, 310 litre hot water storage tank, storage tank protection anode, one direct heat circuit

Our heat pump in detail

Specifics
of AirPro COMFORT

Outdoor unit
Heat pump
AirPro COMFORT

An indoor and an outdoor unit are required for efficient heating and cooling operation with a monobloc heat pump system. The outdoor module of the AirPro COMFORT covers output ranges from 2 to 20 kW and includes the fully integrated refrigeration circuit with all refrigeration components.

With the help of our digital 3D model, the outdoor unit can already be viewed from different angles during the planning phase. Augmented reality (AR) can also be used to virtually position the heat pump at the intended installation site, making system planning easier in advance.

3D representation: AirPro 207 model

Open 3D model in a new window

Indoor unit
Heat pump
AirPro COMFORT

The upright COMFORT indoor unit combines the central hydraulic components of the heat pump system in a compact unit and also enables integrated domestic hot water preparation. In addition to the functions of the STYLE equipment, the module has a hot water storage tank with a capacity of 310 litres, a storage tank protection anode and an integrated direct heat circuit. The complete cooling circuit is housed in the outdoor unit, which means that the indoor installation is focussed on the hydraulic integration.

Innenmodul Wärmepumpe Airflow-M COMFORT 5-20 kW | Hargassner

Technical
details

    AirPro 207– COMFORT
    2 - 7
    5.42
    4.86
    5.00 / 3.61
    197 / 141.6
    A+++ / A++
    39.4
    230 / 50
    3.6
    1505 x 1015 x 715
    695 x 1770 x 878
    241 / 255
    310
    AirPro 310 – COMFORT
    3 - 10
    8.55
    8.44
    5.07 / 4.08
    199.8 / 160.2
    A+++
    39.4
    230 / 50 | 400 / 50
    230: 5.36 | 400: 5.19
    1605 x 1115 x 715
    695 x 1770 x 858
    230V: 266 / 255 | 400V: 276 / 255
    310
    AirPro 515 – COMFORT
    5 - 15
    12.91
    12.33
    5.21 / 3.98
    205.3 / 156.1
    A+++
    40.6
    400 / 50
    8.01
    1705 x 1370 x 905
    695 x 1770 x 878
    350 / 255
    310
    AirPro 620 – COMFORT
    6 - 20
    16.15
    15.97
    5.34 / 4.09
    210.4 / 160.7
    A+++
    40.3
    400 / 50
    10.85
    1955 x 1475 x 905
    695 x 1770 x 878
    401 / 255
    310

    *according to EN 14825 (medium climate)
