Heat Pump

Airflow-M
5–20 kW
STYLE

Integrated hydraulic components
Energy rating A++ / A+++

Download brochure
  • Simple, time-saving installation
  • Space-saving
  • Central control unit for the entire heating system
  • 7" wide colour touch display
  • Intelligent hybrid function

Heat pump STYLE

The wall-mounted hydraulic unit

In addition to the central control unit for the entire heating system, the “STYLE” indoor module also includes the most important hydraulic components. These include a high-efficiency pump, an electric heating rod, magnetic dirt separator, flow sensor, a safety group and an expansion tank with a capacity of 12 litres. The entire refrigeration circuit is also located in the outdoor unit.

Note: Shipping of the Hargassner Airflow-M heat pump will start in February 2025.

Benefits:
Airflow-M STYLE

Download brochure
  • Wide power modulation thanks to Copeland ScrollTM inverter compressor
  • Environmentally friendly refrigerant R452B (GWP 676)
  • 7" colour touch-screen
  • Easy to use: Mobile control or smart home with app & web app
  • Intelligent hybrid function enables perfect combinations
  • Efficient operation at temperatures down to -25°C
  • Flow temperatures up to 65°C possible
  • Standard heating and cooling modes
  • Quick and easy installation
  • Attractive, modern design
  • High weather resistance thanks to powder-coated aluminum housing
  • Low-noise operation according to EN 12102 with only 46 dB
  • Very good energy efficiency with a SCOP of up to 4.76
  • Energy efficiency class up to A+++
Hydraulic components included in addition to the BASIC equipment: Electric heating element with automatic power reduction 3 / 6 / 9 kW, magnetic dirt separator, safety group (pressure gauge, safety valve 3 bar, automatic air vent), expansion tank (12 l)

Our heat pump in detail

Specifics
of Airflow-M STYLE

Outdoor modules heat pump
Airflow-M STYLE

If you want to heat and cool your home sustainably with a monobloc heat pump concept, you always need two separate modules: an indoor and an outdoor module with a power of 5 to 20 kW. The latter includes the entire refrigerant circuit with evaporator, compressor, capacitor and expansion valve.
Our 3D model of the outdoor module provides new perspectives for planning your heat pump. Augmented reality (AR) allows you to place the heat pump in its future location and make an informed decision. Immerse yourself in our 3D visualization and design your energy future intelligently and innovatively!

Open 3D model in a new window

Indoor module
heat pump
Airflow-M STYLE

Using this indoor unit makes controlling your entire heating system – whether for heating purposes or for cooling in the summer months – child’s play thanks to a large-format touch display. The wall-mounted STYLE hydraulic module is equipped as standard with an electronically infinitely variable circulation pump, an automatically adjustable heating rod, a magnetic dirt separator, a flow sensor, an integrated safety group along with a 12-litre expansion tank.

Innenmodul Wärmepumpe Airflow-M STYLE 5-20 kW | Hargassner

Technical
details

Modulation range
Heating capacity at A-7W35*
Heating capacity at A-7W35*
SCOP at 35 / 55°C *
Efficiency of ETAs at 35 / 55°C *
Energy efficiency class at 35 / 55°C *
Sound power level normal / night **
Sound pressure level at a distance of 5m / 8m ***
Supply voltage
Supply voltage
Max. power consumption
Dimensions of outdoor unit
(W x H x D)
Dimensions of indoor unit
(W x H x D)
Weight outdoor unit / indoor unit
Hot water tank
kW
kW
kW
%
dB(A)
dB(A)
V / Hz
A
kW
mm
mm
kg
    AFM 5 – STYLE
    Modulation range 2 - 5 kW
    Heating capacity at A-7W35* 4.98 kW
    Heating capacity at A-7W55* 4.77 kW
    SCOP at 35 / 55°C * 4.09 / 3.25
    Efficiency ETAs at 35 / 55°C * 160.5 / 127.1 %
    Energy efficiency class at 35 / 55°C * A++ / A++
    Sound power level normal / night ** 54 / 51 dB(A)
    Sound pressure level at 5m / 8m distance *** 32/ 28 dB(A)
    Supply voltage 230 / 50 V / Hz
    Connection current 15 A
    Max. power consumption 5.32 kW
    Dimensions of outdoor unit
    (W x H x D)     1150 x 860 x 515 mm
    Dimensions of indoor unit
    (W x H x D)     640 x 770 x 400 mm
    Weight of outdoor unit / indoor unit 129 / 40 kg
    Hot water tank -
    AFM 7 – STYLE
    Modulation range 2 - 7 kW
    Heating capacity at A-7W35* 5.42 kW
    Heating capacity at A-7W55* 5,18 kW
    SCOP at 35 / 55°C * 4.12 / 3.23
    Efficiency ETAs at 35 / 55°C * 161.8 / 126 %
    Energy efficiency class at 35 / 55°C * A++ / A++
    Sound power level normal / night ** 55 / 52 dB(A)
    Sound pressure level at 5m / 8m distance *** 33 / 29 dB(A)
    Supply voltage 230 / 50 V / Hz
    Connection current 15 A
    Max. power consumption 5.32 kW
    Dimensions of outdoor unit
    (W x H x D)     1150 x 860 x 515 mm
    Dimensions of indoor unit
    (W x H x D)     640 x 770 x 400 mm
    Weight of outdoor unit / indoor unit 129 / 40 kg
    Hot water tank -
    AFM 9 – STYLE
    Modulation range 2 - 9 kW
    Heating capacity at A-7W35* 6.62 kW
    Heating capacity at A-7W55* 6.45 kW
    SCOP at 35 / 55°C * 4.21 / 3.34
    Efficiency ETAs at 35 / 55°C * 165.5 / 130.6 %
    Energy efficiency class at 35 / 55°C * A++ / A++
    Sound power level normal / night ** 46 / 43 dB(A)
    Sound pressure level at 5m / 8m distance *** 24 / 20 dB(A)
    Supply voltage 230 / 50 V / Hz
    Connection current 15 A
    Max. power consumption 5.32 kW
    Dimensions of outdoor unit
    (W x H x D)     1390 x 860 x 590 mm
    Dimensions of indoor unit
    (W x H x D)     640 x 770 x 400 mm
    Weight of outdoor unit / indoor unit 148 / 40 kg
    Hot water tank -
    AFM 12 – STYLE
    Modulation range 3 - 12 kW
    Heating capacity at A-7W35* 7.89 kW
    Heating capacity at A-7W55* 7.79 kW
    SCOP at 35 / 55°C * 4.20 / 3.54
    Efficiency ETAs at 35 / 55°C * 165.1 / 138.7 %
    Energy efficiency class at 35 / 55°C * A++ / A++
    Sound power level normal / night ** 48 / 45 dB(A)
    Sound pressure level at 5m / 8m distance *** 26 / 22 dB(A)
    Supply voltage 400 / 50 V / Hz
    Connection current 3 x 12 A
    Max. power consumption 7.4 kW
    Dimensions of outdoor unit
    (W x H x D)     1390 x 860 x 590 mm
    Dimensions of indoor unit
    (W x H x D)     640 x 770 x 400 mm
    Weight of outdoor unit / indoor unit 148 / 40 kg
    Hot water tank -
    AFM 14 – STYLE
    Modulation range 4 - 14 kW
    Heating capacity at A-7W35* 9.57 kW
    Heating capacity at A-7W55* 9.33 kW
    SCOP at 35 / 55°C * 4.73 / 3.38
    Efficiency ETAs at 35 / 55°C * 186.1 / 132.2 %
    Energy efficiency class at 35 / 55°C * A+++ / A++
    Sound power level normal / night ** 50 / 47 dB(A)
    Sound pressure level at 5m / 8m distance *** 28 / 24 dB(A)
    Supply voltage 400 / 50 V / Hz
    Connection current 3 x 12 A
    Max. power consumption 7.4 kW
    Dimensions of outdoor unit
    (W x H x D)     1350 x 1505 x 585 mm
    Dimensions of indoor unit
    (W x H x D)     640 x 770 x 400 mm
    Weight of outdoor unit / indoor unit 210 / 40 kg
    Hot water tank -
    AFM 16 – STYLE
    Modulation range 5 - 16 kW
    Heating capacity at A-7W35* 12.05 kW
    Heating capacity at A-7W55* 11.95 kW
    SCOP at 35 / 55°C * 4.76 / 3.41
    Efficiency ETAs at 35 / 55°C * 187.2 / 133.5 %
    Energy efficiency class at 35 / 55°C * A+++ / A++
    Sound power level normal / night ** 52 / 49 dB(A)
    Sound pressure level at 5m / 8m distance *** 30 / 26 dB(A)
    Supply voltage 400 / 50 V / Hz
    Connection current 3 x 12 A
    Max. power consumption 7.4 kW
    Dimensions of outdoor unit
    (W x H x D)     1350 x 1505 x 585 mm
    Dimensions of indoor unit
    (W x H x D)     640 x 770 x 400 mm
    Weight of outdoor unit / indoor unit 212 / 40 kg
    Hot water tank -
    AFM 18 – STYLE
    Modulation range 5 - 18 kW
    Heating capacity at A-7W35* 13.01 kW
    Heating capacity at A-7W55* 12.87 kW
    SCOP at 35 / 55°C * 4.71 / 3.35
    Efficiency ETAs at 35 / 55°C * 185.2 / 131.0 %
    Energy efficiency class at 35 / 55°C * A+++ / A++
    Sound power level normal / night ** 53 / 50 dB(A)
    Sound pressure level at 5m / 8m distance *** 31 / 27 dB(A)
    Supply voltage 400 / 50 V / Hz
    Connection current 3 x 12 A
    Max. power consumption 7.4 kW
    Dimensions of outdoor unit
    (W x H x D)     1350 x 1505 x 585 mm
    Dimensions of indoor unit
    (W x H x D)     640 x 770 x 400 mm
    Weight of outdoor unit / indoor unit 212 / 40 kg
    Hot water tank -
    AFM 20 – STYLE
    Modulation range 5 - 20 kW
    Heating capacity at A-7W35* 13.78 kW
    Heating capacity at A-7W55* 13.65 kW
    SCOP at 35 / 55°C * 4.69 / 3.23
    Efficiency ETAs at 35 / 55°C * 184.4 / 126.3 %
    Energy efficiency class at 35 / 55°C * A+++ / A++
    Sound power level normal / night ** 54 / 51 dB(A)
    Sound pressure level at 5m / 8m distance *** 32 / 28 dB(A)
    Supply voltage 400 / 50 V / Hz
    Connection current 3 x 12 A
    Max. power consumption 7.4 kW
    Dimensions of outdoor unit
    (W x H x D)     1350 x 1505 x 585 mm
    Dimensions of indoor unit
    (W x H x D)     640 x 770 x 400 mm
    Weight of outdoor unit / indoor unit 212 / 40 kg
    Hot water tank -

    *according to EN 14511 | (medium climate) **according to EN 12102 | ***Free field installation

    Target group
    & possible areas of application

    Detached house

    Semi-detached house

    Low-energy house
